| parameter | symbol | min | max | units | note |
| storage temperature | tstg | -40 | 85 | °c | |
| operating temperature | tc | -40 | 85 | °c | |
| soldering temperature | tsold | --- | 260 | °c | <10s on leads |
| optical input power | pin | --- | -5.0 | dbm | m < 10, resp.<0.8 a/w |
| maximum pa peak current without damage | ipina-max | --- | 6.5 | ma | |
| power supply voltage | vcc | 3.0 | 3.6 | v |
| parameter | symbol | test condition | min | typ | max | unit |
| power supply | vcc | 3.0 | 3.3 | 3.6 | v | |
| tia supply current | icc | vcc=3.3v | 20 | 25 | 40 | ma |
| wavelength | λ | cw | 1260 | 1310 | 1620 | nm |
| breakdown voltage | vbr | id=10ua | 25 | 35 | 45 | v |
| responsivity | r | λ=1310nm,‐30db | - | - | 0.8 | a/w |
| dark current at room temperature | id | vcc= 3.3v, vr= 0.9*vbr, 25°c, no input power | - | - | 100 | na |
| dark current at high temperature | id | vcc= 3.3v, vr= 0.9*vbr, 25°c, no input power | - | - | 600 | na |
| optical return loss | orl | λ@1270nm-1610nm | -27 | db | ||
| optical sensitivity | sen | λ= 1310nm@10.3125 gbps, prbs= 231-1, er= 6db, ber= 10-12 | - | - | -16 | dbm |
| saturation power | psat | -7 | - | - | dbm |
