| parameter | symbol | min | max | units | note |
| ld reserve voltage | vr | 2 | v | ||
| ld forward current | if | 100 | ma | ||
| mpd reverse voltage | vrpd | 15 | v | ||
| mpd forward current | ifpd | 10 | ma | ||
| storage temperature | tstg | -40 | 85 | °c | |
| operating temperature | tc | -40 | 85 | °c | |
| soldering temperature | tsold | 260 | °c | <10s on leads |
| parameter | symbol | test condition | min | typ | max | unit |
| central wavelength and wavelength span |
λc (1471) λc (1491) λc (1511) λc (1531) λc (1551) λc (1571) |
cw, iop=ith 30ma, tc= -40°c ~ 85°c |
1464.5 1484.5 1504.5 1524.5 1544.5 1564.5 |
- | 1477.5 1497.5 1517.5 1537.5 1557.5 1577.5 |
nm |
| spectrum width (-20db) | δλ | cw, iop=ith 30ma | - | - | 1 | nm |
| side mode suppression ratio | smsr | cw, iop=ith 30ma | 35 | - | - | db |
| threshold current |
ith | cw,25℃ | - | - | 15 | ma |
| cw,85℃ | - | - | 30 | ma | ||
| operating voltage | vf | cw, iop=ith 30ma | - | - | 2 | v |
| optical output power | pf | cw, ith 30ma | 1.6 | - | 2.8 | mw |
| slope efficiency | se | cw, iop=ith 30ma | 0.053 | - | 0.094 | mw/ma |
| pd monitor current | im | cw, ith 30ma | 0.1 | - | 1.5 | ma |
| pd dark current | id | vr=5v | - | - | 100 | na |
| tracking error | te | cw, ith 30ma,-40℃~85℃ | -1.5 | - | 1.5 | db |
