single stage free space optical isolator

free space optical isolator is a passive magneto-optic device which transmits light in a certain direction while blocking light in the opposite direction. faraday isolators are based on faraday rotators and fraday effect and constitute the technologically most important type of optical isoloators. optical isolator is widely used in applications that to avoid unwanted light feedback.
the simplest type of polarization-sensitive faraday isolators is comprised of a faraday rotator with magnet, input polarizer and output polarizer. the input polarizer is arranged to act as a filter and only allows linearly polarized light into the rotator. the rotator then rotates the polarization of the input light by 45 degrees and is allowed to exit through the output polarizer.

single stage free space optical isolator feature
high isolation
low insertion loss
high reliability
rohs complaint
compact size
optimized for different wavelengths

single stage free space optical isolator application
transmitter optical sub assembly（tosa）
bi-directional optical sub assembly(bosa)
gpon/epon olt module
optical transmitters and transceivers
optical sensor
laser diode packaging
tunable laser module

single stage free space optical isolator specification

parameters	specification	units
center wavelength	1270~1610	nm
operating wavelength	±20	nm
clear aperture	φ0.4-3.0	mm
insertion loss(λc,23℃)	≤0.3	db
isolation(λc,23℃)	≥35	db
operating temperature	-40 to 85	℃
storage temperature	-40 to 85	℃
max. optical power	300	mw
