single stage standard size in line optical isolator with pmd

in line optical isolator features
low insertion loss
high isolation
telcordia compliant
rohs compliant

in line optical isolator application
fiber optic components
dwdm/cwdm
edfa

standard size single stage in line optical isolator specifications

parameter	specification	unit
center wavelength(λc)	1310/1550 or customized	nm
single stage	sinlge stage with pmd	db
isolation(atλc±15nm)1,mini	32	db
isolation(atλc±15nm)2,mini	22	db
insertion loss (atλc)1,typ	0.45	db
insertion loss(atλc±15nm)2,max	0.6	db
return loss(input/output),min	60/55	db
pdl,max	0.05	db
pmd,max	0.25	ps
opterating temperature range	from -30 to 70	℃
storage temperature range	from -40 to 85	℃
package dimension(l*φ)	30*55	mm

1. tested at 23°c, all sop, and values referenced without connector.
2. tested at 0~70°c, all sop, and values referenced without connector.

standard size single stage in line isolator dimension
