| parameter | unit | parameters |
| center wavelength (λc) | nm | 1064 |
| operating wavelength range | nm | c±5 |
| typ.insertion loss（c at 23 ℃) | db | ≤2.0 |
| max.insertion loss(aow at 23 ℃ ) | db | ≤2.4 |
| peak isolation | db | ≥28 |
| min.isolation(at 23 ℃) | db | ≥22 |
| channel croass talk | db | ≥45 |
| max pdl(at 23 ℃) | db | ≤0.2 |
| return loss | db | ≥50 |
| power handling | mw | 500 |
| fiber type | hi 1060 fiber | |
| operating temperature | ℃ | from - 5 to 70 |
| storage temperature | ℃ | from - 40 to 85 |
| package dimensions | mm | w25.4xl68xh8.4 |
