| parameter | unit | parameters |
| operating wavelength range | nm | 1565-1625 |
| typ.insertion loss（at 23 ℃；aow) | nm | ≤1.0 |
| max.insertion loss(aow;aot) | db | ≤1.2 |
| peak.isolation(at 23 ℃） | db | ≥50 |
| min.isolation(at 23 ℃；aow) | db | ≥35 |
| channel croass talk | db | ≥50 |
| max pdl(at 23 ℃) | db | ≤0.2 |
| max pmd(at 23 ℃) | ps | ≤0.15 |
| return loss | db | ≥55 |
| power handling | mw | 500 |
| fiber type | θ0.9mm loose tube or sm bare fiber | |
| operating temperature | ℃ | from - 5 to 70 |
| storage temperature | ℃ | from - 40 to 85 |
| package dimensions | mm | θ5.5xl50(glass tube size:θ4.6xl30) |
