| parameter | unit | parameters |
| configuration | port 1 to port 2 to port 3 | |
| operating wavelength | nm | 1550±30 |
| typ.insertion loss | db | 0.8 |
| max. insertion loss | db | 1.0 |
| typ.isolation(at 23 ℃） | db | ≥45 |
| min.isolation(at 23 ℃) | db | ≥35 |
| extinction ratio | db | 18(type.)/16(min.) |
| directivity | db | ≥50 |
| direction of incident polarization | db | ≥50 |
| fiber type | pm panda fiber | |
| power handing(cw) | mw | 500 |
| operating temperature | ℃ | from - 5 to 70 |
| storage temperature | ℃ | from - 40 to 85 |
| package dimensions | mm | θ5.5xl50 |
