to-can性能指标 specifications | ||||||||
产品 product | 速率 data rate(gbit/s) | 波长 wavelength (nm) |
pd-tia | cap | 暗电流(na) | 灵敏度sensitivity (dbm) | 响应度(a/w) | |
to 46 | 1.25g pin-tia | 1.25 | 1210~1650 | pin-tia | ball lens | <100 | ≥-30 | >0.85 |
2.5g super-tia | 2.5 | 900~1650 | apd-tia | ball lens | <100 | ≥-30 | >0.90 | |
10g pin-tia | 10 | 1210~1650 | pin-tia | ball lens | <100 | ≥-30 | >0.85 | |
pd | pd910 | / | 850~1700 | pin | 平窗 | <10 | / | >0.85 |
pd920 | / | 850~1700 | pin | 平窗 | <10 | / | >0.85 | |
pd930 | / | 850~1700 | pin | 平窗 | <10 | / | >0.85 | |
apd200 | / | 800~1700 | pin | 平窗 | <100 | / | >0.65 | |
apd500 | / | 800~1700 | pin | 平窗 | <100 | / | >0.65 |
